HARDITO
Displacement: 3,49 cc R.P.M. (max power): 37.000 RPM Practical range: 6.000-45.100 R.P.M. Bore x stroke: 16,26x16,80 mm Sleeve: 7 ports Rear ball bearings: steel Front ball bearings: steel Crankshaft: 14 mm - turbo Carburetor: aluminium - 9mm - slide Glowplug: Turbo (C5TF) Exhaust position: rear Starting: - Weight: 357 g Fuel type: 25% nitro |
|
 |
 |
||
 |
FEATURES
 |
 |
 |
 |
|||||||||||||||||||||||||||||||||||||||||||||||
| Glowplug: The glowplug of engine is a Turbo type glowplug. Turbo glowplugs have a different shape than Standard glowplugs and therefor are not interchange able with engines that are using Standard glowplugs. |
Sleeve: The sleeve is manufactured with 7 transfer ports and an exhaust with booster ports, designed after fluid-dynamics studies, so we increased the maximum power, and taking care of the fuel consumption. |
Crankshaft: The crankshaft is manufactured with a larger bore intake to increase the mixture flow;and has a special shape to optimise gas-flows in the engine. |
Conrod: The R7 conrod is made from a superlight alluminium which has been checked ultrasonic. The specific form of the R7 creates little turbulence inside the engine while running. |
|||||||||||||||||||||||||||||||||||||||||||||||
   |
 |
   |
 |
NOVAROSSI WORLD S.r.l.
